Applications
- Tailings dam bodies, open-pit mine slopes, geological hazard slopes, reservoir and dam banks, highway and railway slopes, and bridge health monitoring
Key Features
- Powerful connectivity: data can still be transmitted over the wireless LAN function when there is no 4G signal or internet access
- Monitoring parameters: high-accuracy surface displacement, acceleration and tilt readings
- Monitoring accuracy: horizontal displacement 2.5 mm + 0.5 ppm; vertical displacement 5 mm + 0.5 ppm
- Communication: 4G, NB-IoT / WiFi, Bluetooth and LoRa
- Edge computing: supports RTK, server-side and on-board static processing, and can trigger sound-and-light alarms directly
- Sensor integration: MEMS-triggered RTK, with power and network supply for RS485 sensors
- Storage: internal memory holds more than 2 years of raw data at a 15-second sampling interval
- Other functions: scheduled sleep, battery monitoring, status monitoring and remote firmware upgrade
- Power: 2 W low consumption with auto start on power-up; with mains connected the built-in battery provides 35 hours of backup operation
- Compact design: integrated all-in-one construction, simple accessories, easy installation and IP68 protection
- GNSS
- Satellite Systems
- GPS:L1C/A, L2C
- BDS:B1I,B2I
- GLONASS: L1OF,L2OF
- Galileo: E1B/C, E5b
